Product Description
A1106Y2  = A1106 (JP Coupler) + 3.5x4.5mm nylon hose
A1106Y5  = A1106 (JP Coupler) - without brake oil hose


A1106USY2  = A1106 (US Coupler) + 3.5x4.5mm nylon hose
A1106USY5  = A1106 (US Coupler) - without brake oil hose



A1106EUY2  = A1106 (EU Coupler) + 3.5x4.5mm nylon hose

A1106EUY5  = A1106 (EU Coupler) - without brake oil hose

A1106Y2
Feature:

1. 15 Liter of capacity (holds up to 3.9 gals of fluid ) which is perfect for cars with large engines without stopping the oil changing during the extraction. FIRSTINFO’s oil extractors are made of polypropylene which can stand up to 35°F~200°F’s fluids.
2. Extract the engine oil, Brake fluid, ATF fluid, and other non-corrosive and non-thick fluid of motorcycles and vehicles. No limits to any places and no need to lift up or crawl under the car to change the oil. *Note: Gasoline, and fluid with high volatility, high corrosion, high alkalinity or acidity high temperature are FORBIDDEN to be used with this extractor.
3. One extra upgraded brake oil silicon hose 4x8mm X 2 Meter (78.7 inch) Long with a check valve to avoid oil back flowing when bleeding. With the storage hose to collect oil hoses easily, and duster cover to avoid any dust and dirt.
4. Fast extraction speed of 1.6L /min. The pneumatic way for higher speed of oil change; just need to connect with an air compressor. Manual operation requires no other equipment; easy to do the oil/fluid changing for DIY anywhere. No need to lift up or crawl under the car to change the oil.
5. With 4 diameters of tubes which can go into the bottom of the oil pan. Nylon oil hoses B: 7.8x9.8mm X 1M C:5.3x6.7mm X 1M D:4x6mm X 1M E:3.5x4.5mm X1M. B hose can be connected to (C, D or E ) hose and it will extend to 2 Meter length. To reach the very bottom of the reservoir and suck up the fluid.

Specification:

1. Air inlet: 1/4"
2. Avg. air con.: 2 cfm @ 90 psi (57 L/min @ 6.3 bar)
3. Fluid temperature range: 1°C- 95°C (35°F- 200°F)
4. Working pressure range: 40~170 psi (2.8~11.7 bar ; 0.28~1.17 mpa)

Standard Accessories:

* 1 pc 4 x 8mm silicon bleeding hose x 2M with one-touch controller and universal rubber adapter
* 1 pc 7.8 x 9.8mm extractor main hose
* 1 pc 5.3 x 6.7mm extension nylon tube
* 1 pc 4 x 6mm extension nylon tube
* 1 pc 3.5 x 4.5mm extension nylon tube
* 1 pc wire dipstick

A1106Y5
Feature:

1. The pneumatic way for a higher speed of 1.6~1.7L /min, extracts engine oil in a 4-cylinder car within 5 minutes. Manual operation requires no other equipment which is easy to do the oil/fluid changing for DIY anywhere. No need to lift up or crawl under the car to change the oil.
2. Provided with fixing valve and safety cup for automatically cutting off extracting. And three air outlets with check valve design -- quick and easy to release the air.
3. With 4 diameters of tubes which can go into the bottom of the oil pan. Nylon oil hoses B: 7.8x9.8mm X 1M C:5.3x6.7mm X 1M D:4x6mm X 1M E:3.5x4.5mm X1M. B hose can be connected to (C, D or E ) hose and it will be 2 Meter length. To reach the very bottom of the reservoir and suck up the fluid.
4. Extract the engine oil, Brake fluid, ATF fluid, and other non-corrosive and non-thick fluid of motorcycles and vehicles. *Note: Gasoline, and fluid with high volatility, high corrosion, high alkalinity or acidity high temperature are FORBIDDEN to be used with this extractor. No limits to any places and no need to lift up or crawl under the car to change oil & fluid..
5. With the storage hose to collect oil hoses easily after using, and duster cover to avoid any dust and dirt. The hose can be purchased individually.

Specification:

1. Air inlet: 1/4"
2. Avg. air con.: 2 cfm @ 90 psi (57 L/min @ 6.3 bar)
3. Fluid temperature range: 1°C- 95°C (35°F- 200°F)
4. Working pressure range: 40~170 psi (2.8~11.7 bar ; 0.28~1.17 mpa)

Standard Accessories:

* 1 pc 7.8 x 9.8mm extractor main hose
* 1 pc 5.3 x 6.7mm extension nylon tube
* 1 pc 4 x 6mm extension nylon tube
* 1 pc 3.5 x 4.5mm extension nylon tube
* 1 pc wire dipstick

Package

1 set / carton

N.W.

4 (KG)

G.W.

4.8  (KG)

SET SIZE

59*25*25 (CM)

Carton SIZE

59*25*25 (CM)

CUFT

1.3'
