Product Description
A1107Y2  = A1107 (JP Coupler) + 3.5x4.5mm nylon hose
A1107Y5  = A1107 (JP Coupler) - without brake oil hose

A1107USY2  = A1107 (US Coupler) + 3.5x4.5mm nylon hose
A1107USY5  = A1107 (US Coupler) - without brake oil hose


A1107EUY2  = A1107 (EU Coupler) + 3.5x4.5mm nylon hose

A1107EUY5  = A1107 (EU Coupler) - without brake oil hose

-----A1107Y2-----
Feature:

1. To extract the engine oil, brake fluid ATF fluid, and other fluid of motorcycles and vehicles. Not limited to any places; perfect for working on vehicles in the garage or outdoors, and also for aquarium.
2. One new brake oil silicon hose 4x8mm X 2 Meter (78.7 inches) with a check valve to avoid backflow when bleeding. The length is longer than normal ones for the longer distance. And comes with an oil stopper to control the speed of extraction.
3. With 4 sizes of tubes which can go into the bottom of the oil pan. Nylon oil hoses B: 7.8x9.8mm X 1M C:5.3x6.7mm X 1M D:4x6mm X 1M E:3.5x4.5mm X1M; B hose can be connected to (C, D or E ) hose and it will extend to 2 Meter length. To reach the very bottom of the reservoir and suck up the fluid.
4. 10L in capacity (holds up to 2.6 gals of fluid )which is perfect for cars with large engines without stopping the oil changing during the extraction.
5. The pneumatic mode for higher speed of oil change; just need to connect with an air compressor. Manual mode requires no other equipment; easy to do the oil/fluid changing for DIY. No need to lift up or crawl under the car to change the oil.

Standard Accessories:

* 1 pc 4 x 8mm silicon bleeding hose x 2M with one-touch controller and universal rubber adapter
* 1 pc 7.8 x 9.8mm extractor main hose
* 1 pc 5.3 x 6.7mm extension nylon tube
* 1 pc 4 x 6mm extension nylon tube
* 1 pc 3.5 x 4.5mm extension nylon tube
* 1 pc wire dipstick


-----A1107Y5-----
Feature:

1. Extract the engine oil, Brake fluid, ATF fluid, and other non-corrosive and non-thick fluid of motorcycles and vehicles. No limit to any places; perfect for working on vehicles in the garage or outdoors, and also for an aquarium. No need to lift up or crawl under the car to change the oil.
2. The pneumatic way for a higher speed of 1.6~1.7L /min, extracts engine oil in a 4 cylinder car within 5 minutes. Manual operation requires no other equipment which is easy to do the oil/fluid changing for DIY.
3. With 4 kinds (B.C.D.E) nylon tubes which can go into the bottom of oil pan; And use hose B to connect with C, D, or E to extend the hose length to 2 Meter (78.7inch) in Total. To reach the very bottom of the reservoir and suck up the fluid. And the extra "E" 3.5 x 4.5mm Nylon hose for the new style vehicles.
4. 10L of capacity (holds up to 2.6 gals of fluid )which is perfect for cars with large engines without stopping the oil changing during the extraction.
5. The hose can be purchased individually. With the storage hose to collect oil hoses easily, and duster cover to avoid any dust and dirt.

Standard Accessories:

* 1 pc 7.8 x 9.8mm extractor main hose
* 1 pc 5.3 x 6.7mm extension nylon tube
* 1 pc 4 x 6mm extension nylon tube
* 1 pc 3.5 x 4.5mm extension nylon tube
* 1 pc wire dipstick

Package

1 set / carton

N.W.

3.2 (KG)

G.W.

3.5 (KG)

SET SIZE

45*28*27 (CM)

Carton SIZE

45*28*27 (CM)

CUFT

1.201'
